Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE

  • Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE
  • Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE
  • Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE
  • Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE
  • Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE
  • Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE
Place of Origin Shandong, China
Brand Name Joyshine
Certification CE, ISO
Price $11,020.00/sets 1-2 sets
Packaging Details Export standard wooden case packaging; <br>Container for bubble vegetable washing machine
Supply Ability 20 Set/Sets per Month Bubble Vegetable Washing Machine

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Year Custom Newest Machine Dimension(L*W*H) 6000*1200*1300mm
Weight 600 KG Automatic Grade Automatic
Voltage 220v/380v Machinery Capacity Customized
Key Machines Cleaning Equipment Product Type Vegetables, Fruit
Name Industrial Air Bubble Fruit Vegetable Processing Washing Machine Custom Can Be Accepted
Machine Material Stainless Steel 304 Made Application Fruits And Vegetables
Usage Washing Fruits & Vegetables Capacity 2000kg/h
Package Export Standard Wooden Packaging After-sales Service Provided Engineers Available To Service Machinery Overseas
HS Code 8438800000 Port Qingdao/Shanghai/Ningbo/Shenzhen
Leave a Message
Product Description
Products Description
China Factory Supply Industrial Air Bubble Fruit Vegetable Processing Washing Machine
This vegetable water bubble vegetables washing machine is designed and widely used in washing various fruits and vegetables with different shapes.
It adopts the bubble surfing, brushing, spraying technology for maximize clean of the objects.
It is an indispensable washing device for the fruit and vegetable or seafood processing, and suitable for all kinds of processing scale enterprise.
Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE 0

Working Principle:

This multifunctional bubble washing machine works through high pressure waterflow and water bubbles to impact and scrub the surface of the cleaned objects
Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE 1
Features:
1
Equipped with a bubble generator to make the objects roll over
High pressure air bubble and spraying water can wash off dirt, sands and other residues
2
Equipped with VFD to better adjust the belt speed
3
Equipped with separate filter tank and water recycling system
4
Equipped with spraying section with clean water for twice washing
The objects are automatically conveyored to spraying section by the conveyor mesh belt
Advantages:
1
Food grade SUS304 stainless steel
2
High cleaning ability, high washing rate
3
Wide range application, suitable for many products
4
No damage to the products
OEM Service
According to the customers' special requirements, there are following optional configurations:
1
Ozone generator for sterilization and disinfection and decomposition of pesticide residues
2
Ultrasonic module through ultrasonic vibration to clean the products completely
3
Air fans to be added at the outlet for simple frying after washing
4
Lifting device can be added to life the mesh belt for easy cleaning of the tank
5
Any other functions you need, tell us freely, we will design special machine for you
Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE 2
Detailed Images
Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE 3
Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE 4
Spray Nozzle
Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE 5
Overflow Gap
Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE 6
Filter Tank
Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE 7
Waste Water Outlet
Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE 8
Twice Spraying Section
Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE 9
Sealing Strips
Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE 10
Control Panel
Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE 11
Vortex Blower
Application
Industrial Guava Citrus Fruit Brush Ozone Disinfecting Bubble Washing Line by JOYSHINE 12
Product Paramenters
Model
Dimension
Weight
Power
Capacity
JS-QP-2500
2500*1000*1300mm
400kg
4.45kw
500kg/h
JS-QP-3000
3000*1200*1300mm
600kg
5.25kw
800kg/h
JS-QP-4000
4000*1200*1300mm
700kg
6.6kw
1000kg/h
JS-QP-5000
5000*1200*1300mm
900kg
8.3kw
1500kg/h
JS-QP-6000
6000*1200*1300mm
1100kg
9.4kw
2000kg/h
OEM: Machine size, configuration and capacity etc can be customized according to your special requirements, Contact for more details please!

This bubble washing machine is widely used with other machines to combine one whole processing line, like vegetable cutting machine, brush polishing machine and air drying machine
